| Thermal
resistance (Rsa) |
|
FHC10025MU <FAN : Expulsion>
|
 |
0.266 deg C/W |
|
FHC10040MU <FAN : Expulsion>
|
|
0.201 deg C/W |
| Testing
specification |
| Dumy Heater : 25mmsq |
| Fan Spec : In
the following table |
|
|
|
|
|
|
FHC10025A
|
Size |
mm
|
100x100xh25
|
|
|
Total Weight |
grams
|
454
|
| FHC10040A |
Size |
mm |
100x100xh40 |
|
Total Weight |
grams |
560 |
| HEAT
SINK |
Material |
6063 Aluminum
|
| |
Finish |
Black anodized
|
| |
Embedded |
Copper 1100 or
1020
|
| FAN
Spec. |
Dimension |
92mmsq x 25.4mm
|
|
Voltage |
DCV
|
12
|
|
Current
AMP |
A
|
024
|
|
Speed |
RPM
|
3400
|
|
Max.
Air Flow |
m3/min
|
1.30
|
|
|
CFM
|
45.90
|
|
Max.
Air Pressure |
mmAq
|
5.0
|
|
|
IN Aq
|
0.197
|
|
Noise
Level |
db[A]
|
36
|
|
Vendor |
ORIENTAL MOTOR
|
|
Model number
|
MD925A-12S
|
|
ALPHA FAN Model # |
M92P
|
|
