| Thermal
resistance (Rsa) |
| PAL8045U
<FAN : Expulsion> |
 |
0.28
deg C/W |
| PAL8045U
<FAN : Induction> |
|
0.32
deg C/W |
| Testing
specification |
| Dumy Heater
: 12.7mmsq |
| Fan Spec : In
the following table |
|
|
|
|
|
|
PAL8045U
|
Overall
height |
mm
|
77
|
|
|
Total Weight |
grams
|
520
|
| |
|
|
| HEAT SINK |
Material |
6063 Aluminum
|
| |
Finish |
Black anodized
|
| |
Embedded |
Copper 1100 or
1020
|
| |
Size |
80mmsq x 45.5height
|
| |
|
|
| FAN Spec. |
Dimension |
80mmsq x 25.4mm
|
|
Voltage |
DCV
|
12
|
|
Current
AMP |
A
|
0.34
|
|
Speed |
RPM
|
4000
|
|
Max.
Air Flow |
m3/min
|
1.32
|
|
|
CFM
|
46.1
|
|
Max.
Air Pressure |
mmAq
|
6.78
|
|
|
IN Aq
|
0.267
|
|
Noise
Level |
db[A]
|
40
|
|
Vendor |
DELTA ELECTRONICS
|
|
Model number
|
AFB0812SH-F00
|
| |
|
|
|
