Heat Sink For Xeon Socket 771

Home - Online Catalog - Xeon Heat Sink Index - Start Online Shopping
U8090C2 for Xeon Socket 771 (For Woodcrest and Dempsey) -- 1U
U8090C2 PICTURE U8090C2 PICTURE

Passive Heat Sink. Suitable for 1U System. Copper Embedded Heat Sink.

BULLET Specification
BULLET Drawing
BULLET Installation Guide
Model Name Description
U8090C2-25NC Non-Anodized Heatsink with captive springs, scerws, standoffs, washers

The U8090C2-25 is a passive heatsink so it must be cooled by ducted air flow.


L8090C2 for Xeon Socket 771 (For Woodcrest and Dempsey) -- 2U
L8090C2 PICTURE L8090C2 PICTURE

Passive Heat Sink. Suitable for 2U System. Copper Embedded Heat Sink.

BULLET Specification
BULLET Drawing
BULLET Installation Guide
Model Name Description
L8090C2-51NC Non-Anodized Heatsink with captive springs, scerws, standoffs, washers

The L8090C2-51 is a passive heatsink so it must be cooled by ducted air flow.
